購買 G2RV-SR500-AP AC100與BYCHPS
購買即有保證
G2RV-SR500-AP AC100
- 型號:
- G2RV-SR500-AP AC100
- 描述:
- RELAY GEN PURPOSE SPDT 50MA 100V
- 無鉛狀態/ RoHS狀態:
- 無鉛/符合RoHS
- 庫存數量:
- 13831 Pieces
簡單介紹
BYCHIPS是 G2RV-SR500-AP AC100的现货代理商，我們有庫存立即運輸，也可供長時間供應。請寄給我們您的G2RV-SR500-AP AC100購買計劃通過電子郵件，我們會根據您的計劃給您最優惠的價格。
產品特性
| 開啟電壓（最大值）: | 80 VAC |
|---|---|
| 關閉電壓（最小）: | 10 VAC |
| 端接類型: | Screwless Clamp |
| 切換電壓: | 30VAC, 36VDC - Max |
| 系列: | G2RV-SR |
| 發布時間: | 40ms |
| 繼電器類型: | General Purpose with Socket |
| 封装: | Bulk |
| 工作溫度: | -40°C ~ 55°C |
| 操作時間: | 20ms |
| 安裝類型: | DIN Rail |
| 濕度敏感度（MSL）: | 1 (Unlimited) |
| 製造商零件編號: | G2RV-SR500-AP AC100 |
| 特徵: | - |
| 展開說明: | General Purpose with Socket Relay SPDT (1 Form C) DIN Rail |
| 描述: | RELAY GEN PURPOSE SPDT 50MA 100V |
| 觸點額定值（電流）: | 50mA |
| 觸點材料: | Silver (Ag), Gold (Au) |
| 聯繫表: | SPDT (1 Form C) |
| 線圈電壓: | 100VAC |
| 線圈類型: | Non Latching |
| 線圈電阻: | - |
| 線圈功率: | 0.8 VA |
| 線圈電流: | 6mA |
| Email: | [email protected] |
