購買 CTLDM303N-M832DS TR與BYCHPS
購買即有保證
CTLDM303N-M832DS TR
- 型號:
- CTLDM303N-M832DS TR
- 描述:
- MOSFET 2N-CH 30V 3.6A TLM832DS
- 無鉛狀態/ RoHS狀態:
- 無鉛/符合RoHS
- 庫存數量:
- 19756 Pieces
簡單介紹
BYCHIPS是 CTLDM303N-M832DS TR的现货代理商，我們有庫存立即運輸，也可供長時間供應。請寄給我們您的CTLDM303N-M832DS TR購買計劃通過電子郵件，我們會根據您的計劃給您最優惠的價格。
產品特性
| VGS（TH）（最大）@標識: | 1.2V @ 250µA |
|---|---|
| 供應商設備封裝: | TLM832DS |
| 系列: | - |
| RDS（ON）（最大值）@標識，柵極電壓: | 40 mOhm @ 1.8A, 4.5V |
| 功率 - 最大: | 1.65W |
| 封装: | Tape & Reel (TR) |
| 封裝/箱體: | 8-TDFN Exposed Pad |
| 其他名稱: | CTLDM303N-M832DS TR LEAD FREE |
| 工作溫度: | -55°C ~ 150°C (TJ) |
| 安裝類型: | Surface Mount |
| 濕度敏感度（MSL）: | 1 (Unlimited) |
| 製造商標準交貨期: | 6 Weeks |
| 製造商零件編號: | CTLDM303N-M832DS TR |
| 輸入電容（Ciss）（Max）@ Vds: | 590pF @ 10V |
| 柵極電荷（Qg）（Max）@ Vgs: | 13nC @ 4.5V |
| FET型: | 2 N-Channel (Dual) |
| FET特點: | Standard |
| 展開說明: | Mosfet Array 2 N-Channel (Dual) 30V 3.6A 1.65W Surface Mount TLM832DS |
| 漏極至源極電壓（Vdss）: | 30V |
| 描述: | MOSFET 2N-CH 30V 3.6A TLM832DS |
| 電流 - 25°C連續排水（Id）: | 3.6A |
| Email: | [email protected] |
