購買 STGFW30H65FB與BYCHPS
購買即有保證
STGFW30H65FB
- 型號:
- STGFW30H65FB
- 製造商:
- ST
- 描述:
- IGBT 650V 60A 58W TO3PF
- 無鉛狀態/ RoHS狀態:
- 無鉛/符合RoHS
- 庫存數量:
- 18094 Pieces
- 數據表:
- STGFW30H65FB.pdf
簡單介紹
BYCHIPS是 STGFW30H65FB的现货代理商，我們有庫存立即運輸，也可供長時間供應。請寄給我們您的STGFW30H65FB購買計劃通過電子郵件，我們會根據您的計劃給您最優惠的價格。
產品特性
| 電壓 - 集電極發射極擊穿（最大）: | 650V |
|---|---|
| 的VCE（on）（最大）@ VGE，IC: | 2V @ 15V, 30A |
| 測試條件: | 400V, 30A, 10 Ohm, 15V |
| Td（開/關）@ 25°C: | 37ns/146ns |
| 開關能量: | 151µJ (on), 293µJ (off) |
| 供應商設備封裝: | TO-3PF-3 |
| 系列: | - |
| 功率 - 最大: | 58W |
| 封装: | Tube |
| 封裝/箱體: | TO-3PFM, SC-93-3 |
| 其他名稱: | 497-15123-5 |
| 工作溫度: | -55°C ~ 175°C (TJ) |
| 安裝類型: | Through Hole |
| 濕度敏感度（MSL）: | 1 (Unlimited) |
| 製造商零件編號: | STGFW30H65FB |
| 輸入類型: | Standard |
| IGBT類型: | Trench Field Stop |
| 柵極電荷: | 149nC |
| 展開說明: | IGBT Trench Field Stop 650V 60A 58W Through Hole TO-3PF-3 |
| 描述: | IGBT 650V 60A 58W TO3PF |
| 電流 - 集電極脈衝（ICM）: | 120A |
| 電流 - 集電極（Ic）（最大）: | 60A |
| Email: | [email protected] |
STGFW30H65FB的相似型號
| 圖片 | 型號 | 製造商 | 描述 | 查看 |
|---|---|---|---|---|
 |
STGFW35HF60W | STMicroelectronics | IGBT 600V 36A 88W TO3PF | 在線詢價 |
 |
STGFW30NC60V | STMicroelectronics | IGBT 600V 36A 80W TO3PF | 在線詢價 |
|
STGFW30V60F | STMicroelectronics | IGBT 600V 60A 58W TO3PF | 在線詢價 |
|
STGFW40V60F | STMicroelectronics | IGBT 600V 80A 62.5W TO-3PF | 在線詢價 |
|
STGFW80V60F | STMicroelectronics | IGBT 600V 120A 79W TO-3PF | 在線詢價 |
|
STGFW30V60DF | STMicroelectronics | IGBT 600V 60A 58W TO-3PF | 在線詢價 |
|
STGFW20V60F | STMicroelectronics | IGBT 600V 40A 52W TO3PF | 在線詢價 |
 |
SGF23N60UFDTU | Fairchild/ON Semiconductor | IGBT 600V 23A 75W TO3PF | 在線詢價 |
|
STGFW20V60DF | STMicroelectronics | IGBT 600V 40A 52W TO-3PF | 在線詢價 |
 |
STGFW40H65FB | STMicroelectronics | IGBT HB 650V 40A ISOWATT218 | 在線詢價 |
 |
FGL60N100BNTD | Fairchild/ON Semiconductor | IGBT 1000V 60A 180W TO264 | 在線詢價 |
|
STGFW20H65FB | STMicroelectronics | IGBT 650V 40A 52W TO3PF | 在線詢價 |
|
STGFW40V60DF | STMicroelectronics | IGBT 600V 80A 62.5W TO-3PF | 在線詢價 |
