購買 SRF1006-251Y與BYCHPS
購買即有保證
SRF1006-251Y
- 型號:
- SRF1006-251Y
- 製造商:
- Bourns, Inc.
- 描述:
- CMC 250UH 1.19A 2LN 400 OHM SMD
- 無鉛狀態/ RoHS狀態:
- 無鉛/符合RoHS
- 庫存數量:
- 19316 Pieces
- 數據表:
- SRF1006-251Y.pdf
簡單介紹
BYCHIPS是 SRF1006-251Y的现货代理商，我們有庫存立即運輸，也可供長時間供應。請寄給我們您的SRF1006-251Y購買計劃通過電子郵件，我們會根據您的計劃給您最優惠的價格。
產品特性
| 額定電壓 - 直流: | 50V |
|---|---|
| 額定電壓 - AC: | - |
| 尺寸/尺寸: | 0.394" L x 0.343" W (10.00mm x 8.70mm) |
| 系列: | SRF1006 |
| 評級: | - |
| 封装: | Tape & Reel (TR) |
| 封裝/箱體: | Horizontal, 4 PC Pad |
| 其他名稱: | SRF1006-251Y-ND SRF1006-251YTR |
| 工作溫度: | -40°C ~ 105°C |
| 行數: | 2 |
| 安裝類型: | Surface Mount |
| 濕度敏感度（MSL）: | 1 (Unlimited) |
| 製造商標準交貨期: | 20 Weeks |
| 製造商零件編號: | SRF1006-251Y |
| 電感@頻率: | 250µH @ 100kHz |
| 頻率對應阻抗: | 400 Ohm @ 5MHz |
| 高度（最大）: | 0.256" (6.50mm) |
| 過濾器類型: | Signal Line |
| 特徵: | - |
| 展開說明: | 250µH @ 100kHz 2 Line Common Mode Choke Surface Mount 400 Ohm @ 5MHz 1.19A DCR 35 mOhm |
| 描述: | CMC 250UH 1.19A 2LN 400 OHM SMD |
| 直流電阻（DCR）（最大值）: | 35 mOhm |
| 卡厚度（mm）: | 1.19A |
| 認證: | - |
| Email: | [email protected] |
SRF1006-251Y的相似型號
| 圖片 | 型號 | 製造商 | 描述 | 查看 |
|---|---|---|---|---|
 |
SRF1006-202Y | Bourns Inc. | CMC 2MH 400MA 2LN 2 KOHM SMD | 在線詢價 |
|
SRF1006-502Y | Bourns Inc. | CMC 5MH 250MA 2LN 5 KOHM SMD | 在線詢價 |
|
SRF1006-402Y | Bourns Inc. | CMC 4MH 300MA 2LN 4 KOHM SMD | 在線詢價 |
|
SRF1006-472Y | Bourns Inc. | CMC 4.7MH 250MA 2LN 6.2 KOHM SMD | 在線詢價 |
|
SRF1006-302Y | Bourns Inc. | CMC 3MH 350MA 2LN 3 KOHM SMD | 在線詢價 |
|
SRF1006-102Y | Bourns Inc. | CMC 1MH 520MA 2LN 1.4 KOHM SMD | 在線詢價 |
|
SRF1006-121Y | Bourns Inc. | CMC 120UH 1.4A 2LN 200 OHM SMD | 在線詢價 |
|
SRF1006-501Y | Bourns Inc. | CMC 500UH 840MA 2LN 800 OHM SMD | 在線詢價 |
