購買 SPP80N06S08AKSA1與BYCHPS
購買即有保證
SPP80N06S08AKSA1
- 型號:
- SPP80N06S08AKSA1
- 描述:
- MOSFET N-CH 55V 80A TO-220
- 無鉛狀態/ RoHS狀態:
- 包含鉛/ RoHS不兼容
- 庫存數量:
- 17398 Pieces
簡單介紹
BYCHIPS是 SPP80N06S08AKSA1的现货代理商，我們有庫存立即運輸，也可供長時間供應。請寄給我們您的SPP80N06S08AKSA1購買計劃通過電子郵件，我們會根據您的計劃給您最優惠的價格。
產品特性
| VGS（TH）（最大）@標識: | 4V @ 250µA |
|---|---|
| 技術: | MOSFET (Metal Oxide) |
| 供應商設備封裝: | PG-TO220-3-1 |
| 系列: | SIPMOS® |
| RDS（ON）（最大值）@標識，柵極電壓: | 8 mOhm @ 80A, 10V |
| 功率耗散（最大）: | 300W (Tc) |
| 封装: | Tube |
| 封裝/箱體: | TO-220-3 |
| 其他名稱: | SP000054054 SP000084810 SPP80N06S-08 SPP80N06S-08-ND SPP80N06S08 |
| 工作溫度: | -55°C ~ 175°C (TJ) |
| 安裝類型: | Through Hole |
| 濕度敏感度（MSL）: | 1 (Unlimited) |
| 製造商零件編號: | SPP80N06S08AKSA1 |
| 輸入電容（Ciss）（Max）@ Vds: | 3660pF @ 25V |
| 柵極電荷（Qg）（Max）@ Vgs: | 187nC @ 10V |
| FET型: | N-Channel |
| FET特點: | - |
| 展開說明: | N-Channel 55V 80A (Tc) 300W (Tc) Through Hole PG-TO220-3-1 |
| 漏極至源極電壓（Vdss）: | 55V |
| 描述: | MOSFET N-CH 55V 80A TO-220 |
| 電流 - 25°C連續排水（Id）: | 80A (Tc) |
| Email: | [email protected] |
