購買 P0597NL與BYCHPS
購買即有保證
P0597NL
- 型號:
- P0597NL
- 描述:
- INDUCT ARRAY 2 COIL 5.7UH SMD
- 無鉛狀態/ RoHS狀態:
- 無鉛/符合RoHS
- 庫存數量:
- 17263 Pieces
- 數據表:
- P0597NL.pdf
簡單介紹
BYCHIPS是 P0597NL的现货代理商，我們有庫存立即運輸，也可供長時間供應。請寄給我們您的P0597NL購買計劃通過電子郵件，我們會根據您的計劃給您最優惠的價格。
產品特性
| 公差: | ±15% |
|---|---|
| 測試電感 - 串聯連接: | 22.8µH |
| 尺寸/尺寸: | 1.220" L x 1.000" W (30.99mm x 25.40mm) |
| 屏蔽: | Unshielded |
| 系列: | HCCI-80 |
| 封装: | Tube |
| 封裝/箱體: | Nonstandard |
| 其他名稱: | 553-2735 553-2735-5 553-2735-ND P0597NL-ND |
| 工作溫度: | -40°C ~ 130°C |
| 線圈的數目: | 2 |
| 安裝類型: | Surface Mount |
| 濕度敏感度（MSL）: | 1 (Unlimited) |
| 製造商標準交貨期: | 12 Weeks |
| 製造商零件編號: | P0597NL |
| 電感 - 並行連接: | 5.7µH |
| 高度: | 0.500" (12.70mm) |
| 展開說明: | Unshielded Coil Inductor Array Inductance - Connected in Series Inductance - Connected in Parallel 2.5 mOhm Max DC Resistance (DCR) - Parallel Nonstandard |
| 描述: | INDUCT ARRAY 2 COIL 5.7UH SMD |
| 直流電阻（DCR） - 系列: | 10.1 mOhm Max |
| 直流電阻（DCR） - 並聯: | 2.5 mOhm Max |
| 電流額定值 - 系列: | 13.5A |
| 電流額定值 - 並聯: | 27A |
| Email: | [email protected] |
P0597NL的相似型號
| 圖片 | 型號 | 製造商 | 描述 | 查看 |
|---|---|---|---|---|
 |
PM610-02 | Bourns Inc. | INDUCT ARRAY 6 COIL 78.4UH SMD | 在線詢價 |
 |
SRF1260A-2R2Y | Bourns Inc. | INDUCT ARRAY 2 COIL 2.2UH SMD | 在線詢價 |
 |
CMT4545-120M | API Delevan Inc. | INDUCT ARRAY 2 COIL 33UH SMD | 在線詢價 |
 |
CTX8-2-R | Eaton | INDUCT ARRAY 2 COIL 7.94UH SMD | 在線詢價 |
 |
P0177NL | Pulse Electronics Corporation | INDUCT ARRAY 2 COIL 10.4UH SMD | 在線詢價 |
 |
SRF0703A-150M | Bourns Inc. | INDUCT ARRAY 2 COIL 15UH SMD | 在線詢價 |
|
SRF1260A-8R2Y | Bourns Inc. | INDUCT ARRAY 2 COIL 8.2UH SMD | 在線詢價 |
 |
P0597NLT | Pulse Electronics Corporation | INDUCT ARRAY 2 COIL 5.7UH SMD | 在線詢價 |
 |
HM78D-1210470MLFTR | TT Electronics/BI Magnetics | INDUCT ARRAY 2 COIL 47UH SMD | 在線詢價 |
