購買 MPQ6502與BYCHPS
購買即有保證
MPQ6502
- 型號:
- MPQ6502
- 描述:
- TRANS 2NPN/2PNP 30V 0.5A
- 無鉛狀態/ RoHS狀態:
- 包含鉛/ RoHS不兼容
- 庫存數量:
- 18181 Pieces
- 數據表:
- MPQ6502.pdf
簡單介紹
BYCHIPS是 MPQ6502的现货代理商，我們有庫存立即運輸，也可供長時間供應。請寄給我們您的MPQ6502購買計劃通過電子郵件，我們會根據您的計劃給您最優惠的價格。
產品特性
| 電壓 - 集電極發射極擊穿（最大）: | 30V |
|---|---|
| Vce飽和（最大）@ IB，IC: | 1.4V @ 30mA, 300mA |
| 晶體管類型: | 2 NPN, 2 PNP |
| 供應商設備封裝: | TO-116 |
| 系列: | - |
| 功率 - 最大: | 650mW |
| 封装: | Tube |
| 封裝/箱體: | 14-DIP (0.300", 7.62mm) |
| 其他名稱: | MPQ6426 |
| 工作溫度: | -65°C ~ 150°C (TJ) |
| 安裝類型: | Through Hole |
| 濕度敏感度（MSL）: | 1 (Unlimited) |
| 製造商標準交貨期: | 12 Weeks |
| 製造商零件編號: | MPQ6502 |
| 頻率 - 轉換: | 200MHz |
| 展開說明: | Bipolar (BJT) Transistor Array 2 NPN, 2 PNP 30V 500mA 200MHz 650mW Through Hole TO-116 |
| 描述: | TRANS 2NPN/2PNP 30V 0.5A |
| 直流電流增益（HFE）（最小值）@ IC，的Vce: | 30 @ 300mA, 10V |
| 電流 - 集電極截止（最大）: | 30nA (ICBO) |
| 電流 - 集電極（Ic）（最大）: | 500mA |
| Email: | [email protected] |
MPQ6502的相似型號
| 圖片 | 型號 | 製造商 | 描述 | 查看 |
|---|---|---|---|---|
 |
IMT17-7 | Diodes Incorporated | TRANS 2PNP 50V 0.5A SOT26 | 在線詢價 |
