購買 MGN1X-AC24與BYCHPS
購買即有保證
MGN1X-AC24
- 型號:
- MGN1X-AC24
- 描述:
- RELAY GEN PURPOSE SPST 30A 24V
- 無鉛狀態/ RoHS狀態:
- 無鉛/符合RoHS
- 庫存數量:
- 18921 Pieces
- 數據表:
- MGN1X-AC24.pdf
簡單介紹
BYCHIPS是 MGN1X-AC24的现货代理商，我們有庫存立即運輸，也可供長時間供應。請寄給我們您的MGN1X-AC24購買計劃通過電子郵件，我們會根據您的計劃給您最優惠的價格。
產品特性
| 開啟電壓（最大值）: | 20.4 VAC |
|---|---|
| 關閉電壓（最小）: | - |
| 端接類型: | Screw Terminal |
| 切換電壓: | 600VAC, 28VDC - Max |
| 系列: | MGN |
| 發布時間: | 30ms |
| 繼電器類型: | General Purpose |
| 封装: | Bulk |
| 其他名稱: | MGN1XAC24 Z260 |
| 工作溫度: | -45°C ~ 80°C |
| 操作時間: | 30ms |
| 安裝類型: | Chassis Mount |
| 濕度敏感度（MSL）: | 1 (Unlimited) |
| 製造商零件編號: | MGN1X-AC24 |
| 特徵: | Insulation - Class F |
| 展開說明: | General Purpose Relay SPST-NO (1 Form X) 24VAC Coil Chassis Mount |
| 描述: | RELAY GEN PURPOSE SPST 30A 24V |
| 觸點額定值（電流）: | 30A |
| 觸點材料: | - |
| 聯繫表: | SPST-NO (1 Form X) |
| 線圈電壓: | 24VAC |
| 線圈類型: | Non Latching |
| 線圈電阻: | 11.5 Ohms |
| 線圈功率: | 9.5 VA |
| 線圈電流: | 396mA |
| Email: | [email protected] |
