購買 MA2C71900A與BYCHPS
購買即有保證
MA2C71900A
- 型號:
- MA2C71900A
- 製造商:
- Panasonic
- 描述:
- DIODE SCHOTTKY 40V 500MA DO34
- 無鉛狀態/ RoHS狀態:
- 無鉛/符合RoHS
- 庫存數量:
- 19553 Pieces
- 數據表:
- MA2C71900A.pdf
簡單介紹
BYCHIPS是 MA2C71900A的现货代理商，我們有庫存立即運輸，也可供長時間供應。請寄給我們您的MA2C71900A購買計劃通過電子郵件，我們會根據您的計劃給您最優惠的價格。
產品特性
| 電壓 - 正向（Vf）（最大）: | 550mV @ 500mA |
|---|---|
| 電壓 - （Vr）（最大）: | 40V |
| 供應商設備封裝: | DO-34 |
| 速度: | Fast Recovery = 200mA (Io) |
| 系列: | - |
| 反向恢復時間（trr）: | 5ns |
| 封装: | Cut Tape (CT) |
| 封裝/箱體: | DO-204AG, DO-34, Axial |
| 其他名稱: | MA2C71900ACT |
| 工作溫度 - 結: | 125°C (Max) |
| 安裝類型: | Through Hole |
| 濕度敏感度（MSL）: | 1 (Unlimited) |
| 製造商零件編號: | MA2C71900A |
| 展開說明: | Diode Schottky 40V 500mA Through Hole DO-34 |
| 二極管類型: | Schottky |
| 描述: | DIODE SCHOTTKY 40V 500MA DO34 |
| 電流 - Vr時反向漏電: | 100µA @ 35V |
| 電流 - 平均整流（Io）: | 500mA |
| 電容@ Vr，F時: | 60pF @ 0V, 1MHz |
| Email: | [email protected] |
