購買 IXTT82N25P與BYCHPS
購買即有保證
IXTT82N25P
- 型號:
- IXTT82N25P
- 製造商:
- IXYS Corporation
- 描述:
- MOSFET N-CH 250V 82A TO-268
- 無鉛狀態/ RoHS狀態:
- 無鉛/符合RoHS
- 庫存數量:
- 18420 Pieces
- 數據表:
- IXTT82N25P.pdf
簡單介紹
BYCHIPS是 IXTT82N25P的现货代理商，我們有庫存立即運輸，也可供長時間供應。請寄給我們您的IXTT82N25P購買計劃通過電子郵件，我們會根據您的計劃給您最優惠的價格。
產品特性
| VGS（TH）（最大）@標識: | 5V @ 250µA |
|---|---|
| Vgs（最大）: | ±20V |
| 技術: | MOSFET (Metal Oxide) |
| 供應商設備封裝: | TO-268 |
| 系列: | PolarHT™ |
| RDS（ON）（最大值）@標識，柵極電壓: | 35 mOhm @ 41A, 10V |
| 功率耗散（最大）: | 500W (Tc) |
| 封装: | Tube |
| 封裝/箱體: | TO-268-3, D³Pak (2 Leads + Tab), TO-268AA |
| 工作溫度: | -55°C ~ 150°C (TJ) |
| 安裝類型: | Surface Mount |
| 濕度敏感度（MSL）: | 1 (Unlimited) |
| 製造商標準交貨期: | 8 Weeks |
| 製造商零件編號: | IXTT82N25P |
| 輸入電容（Ciss）（Max）@ Vds: | 4800pF @ 25V |
| 柵極電荷（Qg）（Max）@ Vgs: | 142nC @ 10V |
| FET型: | N-Channel |
| FET特點: | - |
| 展開說明: | N-Channel 250V 82A (Tc) 500W (Tc) Surface Mount TO-268 |
| 驅動電壓（最大Rds開，最小Rds開）: | 10V |
| 漏極至源極電壓（Vdss）: | 250V |
| 描述: | MOSFET N-CH 250V 82A TO-268 |
| 電流 - 25°C連續排水（Id）: | 82A (Tc) |
| Email: | [email protected] |
