購買 IRFU5305PBF與BYCHPS
購買即有保證
IRFU5305PBF
- 型號:
- IRFU5305PBF
- 描述:
- MOSFET P-CH 55V 31A I-PAK
- 無鉛狀態/ RoHS狀態:
- 無鉛/符合RoHS
- 庫存數量:
- 18574 Pieces
- 數據表:
- IRFU5305PBF.pdf
簡單介紹
BYCHIPS是 IRFU5305PBF的现货代理商，我們有庫存立即運輸，也可供長時間供應。請寄給我們您的IRFU5305PBF購買計劃通過電子郵件，我們會根據您的計劃給您最優惠的價格。
產品特性
| VGS（TH）（最大）@標識: | 4V @ 250µA |
|---|---|
| Vgs（最大）: | ±20V |
| 技術: | MOSFET (Metal Oxide) |
| 供應商設備封裝: | IPAK (TO-251) |
| 系列: | HEXFET® |
| RDS（ON）（最大值）@標識，柵極電壓: | 65 mOhm @ 16A, 10V |
| 功率耗散（最大）: | 110W (Tc) |
| 封装: | Tube |
| 封裝/箱體: | TO-251-3 Short Leads, IPak, TO-251AA |
| 其他名稱: | *IRFU5305PBF SP001550274 |
| 工作溫度: | -55°C ~ 175°C (TJ) |
| 安裝類型: | Through Hole |
| 濕度敏感度（MSL）: | 1 (Unlimited) |
| 製造商標準交貨期: | 12 Weeks |
| 製造商零件編號: | IRFU5305PBF |
| 輸入電容（Ciss）（Max）@ Vds: | 1200pF @ 25V |
| 柵極電荷（Qg）（Max）@ Vgs: | 63nC @ 10V |
| FET型: | P-Channel |
| FET特點: | - |
| 展開說明: | P-Channel 55V 31A (Tc) 110W (Tc) Through Hole IPAK (TO-251) |
| 驅動電壓（最大Rds開，最小Rds開）: | 10V |
| 漏極至源極電壓（Vdss）: | 55V |
| 描述: | MOSFET P-CH 55V 31A I-PAK |
| 電流 - 25°C連續排水（Id）: | 31A (Tc) |
| Email: | [email protected] |
