購買 HHXB500ARA680MHA0G與BYCHPS
購買即有保證
HHXB500ARA680MHA0G
- 型號:
- HHXB500ARA680MHA0G
- 製造商:
- Nippon Chemi-Con
- 描述:
- CAP ALUM POLY HYB 68UF 50V SMD
- 無鉛狀態/ RoHS狀態:
- 無鉛/符合RoHS
- 庫存數量:
- 17929 Pieces
簡單介紹
BYCHIPS是 HHXB500ARA680MHA0G的现货代理商，我們有庫存立即運輸，也可供長時間供應。請寄給我們您的HHXB500ARA680MHA0G購買計劃通過電子郵件，我們會根據您的計劃給您最優惠的價格。
產品特性
| 額定電壓: | 50V |
|---|---|
| 類型: | Hybrid |
| 公差: | ±20% |
| 表面貼裝佔地面積: | 0.327" L x 0.327" W (8.30mm x 8.30mm) |
| 尺寸/尺寸: | 0.315" Dia (8.00mm) |
| 系列: | Automotive, AEC-Q200, HXB |
| 波紋電流 - 低頻: | - |
| 紋波電流 - 高頻: | 1.8A @ 100kHz |
| 封装: | Tape & Reel (TR) |
| 封裝/箱體: | Radial, Can - SMD |
| 其他名稱: | 565-4190-2 HHXB500ARA680MHA0G-ND |
| 工作溫度: | -55°C ~ 105°C |
| 安裝類型: | Surface Mount |
| 濕度敏感度（MSL）: | 1 (Unlimited) |
| 製造商標準交貨期: | 15 Weeks |
| 製造商零件編號: | HHXB500ARA680MHA0G |
| 壽命@溫度。: | 5000 Hrs @ 105°C |
| 引線間距: | - |
| 阻抗: | - |
| 高度 - 座高（最大）: | 0.406" (10.30mm) |
| 展開說明: | 68µF ±20% 50V Aluminum Polymer Capacitor Radial, Can - SMD 30 mOhm 5000 Hrs @ 105°C |
| ESR（等效串聯電阻）: | 30 mOhm |
| 描述: | CAP ALUM POLY HYB 68UF 50V SMD |
| 電容: | 68µF |
| 應用: | Automotive |
| Email: | [email protected] |
