購買 HF12-1A54-8與BYCHPS
購買即有保證
HF12-1A54-8
- 型號:
- HF12-1A54-8
- 描述:
- RELAY RF SPST 1.5A 12V
- 無鉛狀態/ RoHS狀態:
- 無鉛/符合RoHS
- 庫存數量:
- 16624 Pieces
- 數據表:
- HF12-1A54-8.pdf
簡單介紹
BYCHIPS是 HF12-1A54-8的现货代理商，我們有庫存立即運輸，也可供長時間供應。請寄給我們您的HF12-1A54-8購買計劃通過電子郵件，我們會根據您的計劃給您最優惠的價格。
產品特性
| 開啟電壓（最大值）: | 8.4 VDC |
|---|---|
| 關閉電壓（最小）: | 1.8 VDC |
| 端接類型: | PC Pin |
| 切換電壓: | 500VAC, 500VDC - Max |
| 系列: | HF |
| 發布時間: | 1ms |
| 繼電器類型: | RF |
| 封装: | Bulk |
| 其他名稱: | 8612154004 HF121A54-8 HF121A54-8-ND Q1860636 |
| 工作溫度: | -40°C ~ 85°C |
| 操作時間: | 3ms |
| 安裝類型: | Through Hole |
| 濕度敏感度（MSL）: | 1 (Unlimited) |
| 製造商標準交貨期: | 10 Weeks |
| 製造商零件編號: | HF12-1A54-8 |
| 特徵: | - |
| 展開說明: | RF Relay SPST-NO (1 Form A) Through Hole |
| 描述: | RELAY RF SPST 1.5A 12V |
| 觸點額定值（電流）: | 1.5A |
| 觸點材料: | - |
| 聯繫表: | SPST-NO (1 Form A) |
| 線圈電壓: | 12VDC |
| 線圈類型: | Non Latching |
| 線圈電阻: | 250 Ohms |
| 線圈功率: | 575 mW |
| 線圈電流: | 47.9mA |
| Email: | [email protected] |
