購買 G6HK-2-DC9與BYCHPS
購買即有保證
G6HK-2-DC9
- 型號:
- G6HK-2-DC9
- 製造商:
- Omron
- 描述:
- RELAY TELECOM DPDT 1A 9V
- 無鉛狀態/ RoHS狀態:
- 無鉛/符合RoHS
- 庫存數量:
- 16319 Pieces
- 數據表:
- G6HK-2-DC9.pdf
簡單介紹
BYCHIPS是 G6HK-2-DC9的现货代理商，我們有庫存立即運輸，也可供長時間供應。請寄給我們您的G6HK-2-DC9購買計劃通過電子郵件，我們會根據您的計劃給您最優惠的價格。
產品特性
| 開啟電壓（最大值）: | 6.75 VDC |
|---|---|
| 關閉電壓（最小）: | - |
| 端接類型: | PC Pin |
| 切換電壓: | 125VAC, 110VDC - Max |
| 系列: | G6H |
| 發布時間: | 3ms |
| 繼電器類型: | Telecom |
| 封装: | Tube |
| 其他名稱: | G6HK-2-DC9-ND G6HK1026H G6HK29DC G6HK2DC9 Z2545 |
| 工作溫度: | -40°C ~ 70°C |
| 操作時間: | 3ms |
| 安裝類型: | Through Hole |
| 製造商零件編號: | G6HK-2-DC9 |
| 特徵: | - |
| 展開說明: | Telecom Relay DPDT (2 Form C) Through Hole |
| 描述: | RELAY TELECOM DPDT 1A 9V |
| 觸點額定值（電流）: | 1A |
| 觸點材料: | Silver (Ag), Gold (Au) |
| 聯繫表: | DPDT (2 Form C) |
| 線圈電壓: | 9VDC |
| 線圈類型: | Latching, Dual Coil |
| 線圈電阻: | 405 Ohms |
| 線圈功率: | 200 mW |
| 線圈電流: | 22.2mA |
| Email: | [email protected] |
