購買 G2R-1A-T-AC120與BYCHPS
購買即有保證
G2R-1A-T-AC120
- 型號:
- G2R-1A-T-AC120
- 描述:
- RELAY GEN PURPOSE SPST 10A 120V
- 無鉛狀態/ RoHS狀態:
- 無鉛/符合RoHS
- 庫存數量:
- 12388 Pieces
簡單介紹
BYCHIPS是 G2R-1A-T-AC120的现货代理商，我們有庫存立即運輸，也可供長時間供應。請寄給我們您的G2R-1A-T-AC120購買計劃通過電子郵件，我們會根據您的計劃給您最優惠的價格。
產品特性
| 開啟電壓（最大值）: | 96 VAC |
|---|---|
| 關閉電壓（最小）: | 36 VAC |
| 端接類型: | Quick Connect - 0.187" (4.7mm) |
| 切換電壓: | 380VAC, 125VDC - Max |
| 系列: | G2R |
| 發布時間: | 10ms |
| 繼電器類型: | General Purpose |
| 封装: | Tray |
| 其他名稱: | G2R-1A-T-AC120-ND G2R1ATAC120 Z5901 |
| 工作溫度: | -40°C ~ 70°C |
| 操作時間: | 15ms |
| 安裝類型: | Chassis Mount |
| 濕度敏感度（MSL）: | 1 (Unlimited) |
| 製造商標準交貨期: | 11 Weeks |
| 製造商零件編號: | G2R-1A-T-AC120 |
| 特徵: | Sealed - Flux Protection |
| 展開說明: | General Purpose Relay SPST-NO (1 Form A) 120VAC Coil Chassis Mount |
| 描述: | RELAY GEN PURPOSE SPST 10A 120V |
| 觸點額定值（電流）: | 10A |
| 觸點材料: | Silver Alloy |
| 聯繫表: | SPST-NO (1 Form A) |
| 線圈電壓: | 120VAC |
| 線圈類型: | Non Latching |
| 線圈電阻: | 6.5 kOhms |
| 線圈功率: | 0.9 VA |
| 線圈電流: | 7.5mA |
| Email: | [email protected] |
