購買 FGH80N60FD2TU與BYCHPS
購買即有保證
FGH80N60FD2TU
- 型號:
- FGH80N60FD2TU
- 描述:
- IGBT 600V 80A 290W TO247
- 無鉛狀態/ RoHS狀態:
- 無鉛/符合RoHS
- 庫存數量:
- 19026 Pieces
簡單介紹
BYCHIPS是 FGH80N60FD2TU的现货代理商，我們有庫存立即運輸，也可供長時間供應。請寄給我們您的FGH80N60FD2TU購買計劃通過電子郵件，我們會根據您的計劃給您最優惠的價格。
產品特性
| 電壓 - 集電極發射極擊穿（最大）: | 600V |
|---|---|
| 的VCE（on）（最大）@ VGE，IC: | 2.4V @ 15V, 40A |
| 測試條件: | 400V, 40A, 10 Ohm, 15V |
| Td（開/關）@ 25°C: | 21ns/126ns |
| 開關能量: | 1mJ (on), 520µJ (off) |
| 供應商設備封裝: | TO-247 |
| 系列: | - |
| 反向恢復時間（trr）: | 61ns |
| 功率 - 最大: | 290W |
| 封装: | Tube |
| 封裝/箱體: | TO-247-3 |
| 工作溫度: | -55°C ~ 150°C (TJ) |
| 安裝類型: | Through Hole |
| 濕度敏感度（MSL）: | 1 (Unlimited) |
| 製造商標準交貨期: | 37 Weeks |
| 製造商零件編號: | FGH80N60FD2TU |
| 輸入類型: | Standard |
| IGBT類型: | Field Stop |
| 柵極電荷: | 120nC |
| 展開說明: | IGBT Field Stop 600V 80A 290W Through Hole TO-247 |
| 描述: | IGBT 600V 80A 290W TO247 |
| 電流 - 集電極脈衝（ICM）: | 160A |
| 電流 - 集電極（Ic）（最大）: | 80A |
| Email: | [email protected] |
FGH80N60FD2TU的相似型號
| 圖片 | 型號 | 製造商 | 描述 | 查看 |
|---|---|---|---|---|
 |
IXGT50N60B | IXYS | IGBT 600V 75A 300W TO268 | 在線詢價 |
 |
FGA30N120FTDTU | Fairchild/ON Semiconductor | IGBT 1200V 60A 339W TO3P | 在線詢價 |
 |
APT68GA60LD40 | Microsemi Corporation | IGBT 600V 121A 520W TO-264 | 在線詢價 |
|
FGA90N33ATDTU | Fairchild/ON Semiconductor | IGBT 330V 90A 223W TO3P | 在線詢價 |
 |
IRG4BC30W-STRRP | Infineon Technologies | IGBT 600V 23A 100W D2PAK | 在線詢價 |
 |
IXGX50N60BD1 | IXYS | IGBT 600V 75A 300W TO247 | 在線詢價 |
 |
FGH80N60FDTU | Fairchild/ON Semiconductor | IGBT 600V 80A 290W TO247 | 在線詢價 |
|
IRG4BC20UDSTRLP | Infineon Technologies | IGBT 600V 13A 60W D2PAK | 在線詢價 |
|
FGA25N120ANTDTU_F109 | Fairchild/ON Semiconductor | IGBT 1200V 50A 312W TO3P | 在線詢價 |
 |
NGD15N41CLT4 | ON Semiconductor | IGBT 440V 15A 107W DPAK | 在線詢價 |
|
IXGT20N60B | IXYS | IGBT 600V 40A 150W TO268 | 在線詢價 |
|
IRG4BC30W-STRL | Infineon Technologies | IGBT 600V 23A 100W D2PAK | 在線詢價 |
 |
RJH60D7DPQ-E0#T2 | Renesas Electronics America | IGBT 600V 90A 300W TO-247 | 在線詢價 |
