購買 DRAQ127-470-R與BYCHPS
購買即有保證
DRAQ127-470-R
- 型號:
- DRAQ127-470-R
- 製造商:
- Bussmann (Eaton)
- 描述:
- INDUCT ARRAY 2 COIL 47.9UH SMD
- 無鉛狀態/ RoHS狀態:
- 無鉛/符合RoHS
- 庫存數量:
- 15171 Pieces
簡單介紹
BYCHIPS是 DRAQ127-470-R的现货代理商，我們有庫存立即運輸，也可供長時間供應。請寄給我們您的DRAQ127-470-R購買計劃通過電子郵件，我們會根據您的計劃給您最優惠的價格。
產品特性
| 公差: | ±25% |
|---|---|
| 測試電感 - 串聯連接: | 192µH |
| 尺寸/尺寸: | 0.480" L x 0.480" W (12.20mm x 12.20mm) |
| 屏蔽: | Shielded |
| 系列: | Automotive, AEC-Q200, DRAQ127 |
| 封装: | Tape & Reel (TR) |
| 封裝/箱體: | Nonstandard |
| 其他名稱: | 283-4518-2 |
| 工作溫度: | -40°C ~ 165°C |
| 線圈的數目: | 2 |
| 安裝類型: | Surface Mount |
| 濕度敏感度（MSL）: | 1 (Unlimited) |
| 製造商標準交貨期: | 13 Weeks |
| 製造商零件編號: | DRAQ127-470-R |
| 電感 - 並行連接: | 47.9µH |
| 高度: | 0.315" (8.00mm) |
| 展開說明: | Shielded Coil Inductor Array Inductance - Connected in Series Inductance - Connected in Parallel 110 mOhm Max DC Resistance (DCR) - Parallel Nonstandard |
| 描述: | INDUCT ARRAY 2 COIL 47.9UH SMD |
| 直流電阻（DCR） - 系列: | 440 mOhm Max |
| 直流電阻（DCR） - 並聯: | 110 mOhm Max |
| 當前飽和度 - 系列: | 2.03A |
| 當前飽和度 - 平行: | 4.07A |
| 電流額定值 - 系列: | 1.31A |
| 電流額定值 - 並聯: | 2.62A |
| Email: | [email protected] |
DRAQ127-470-R的相似型號
| 圖片 | 型號 | 製造商 | 描述 | 查看 |
|---|---|---|---|---|
 |
DRAQ127-220-R | Eaton | INDUCT ARRAY 2 COIL 22UH SMD | 在線詢價 |
|
DRAQ127-150-R | Eaton | INDUCT ARRAY 2 COIL 14.9UH SMD | 在線詢價 |
|
DRAQ127-100-R | Eaton | INDUCT ARRAY 2 COIL 9.63UH SMD | 在線詢價 |
|
DRAQ127-330-R | Eaton | INDUCT ARRAY 2 COIL 32UH SMD | 在線詢價 |
 |
P0174NL | Pulse Electronics Corporation | INDUCT ARRAY 2 COIL 2.2UH SMD | 在線詢價 |
 |
PF0553.473NL | Pulse Electronics Corporation | INDUCT ARRAY 2 COIL 47UH SMD | 在線詢價 |
