購買 DMP4015SPSQ-13與BYCHPS
購買即有保證
DMP4015SPSQ-13
- 型號:
- DMP4015SPSQ-13
- 描述:
- MOSFET P-CH 40V 8.5A POWER
- 無鉛狀態/ RoHS狀態:
- 無鉛/符合RoHS
- 庫存數量:
- 17328 Pieces
簡單介紹
BYCHIPS是 DMP4015SPSQ-13的现货代理商，我們有庫存立即運輸，也可供長時間供應。請寄給我們您的DMP4015SPSQ-13購買計劃通過電子郵件，我們會根據您的計劃給您最優惠的價格。
產品特性
| VGS（TH）（最大）@標識: | 2.5V @ 250µA |
|---|---|
| Vgs（最大）: | ±25V |
| 技術: | MOSFET (Metal Oxide) |
| 供應商設備封裝: | PowerDI5060-8 |
| 系列: | - |
| RDS（ON）（最大值）@標識，柵極電壓: | 11 mOhm @ 9.8A, 10V |
| 功率耗散（最大）: | 1.3W (Ta) |
| 封装: | Tape & Reel (TR) |
| 封裝/箱體: | 8-PowerTDFN |
| 其他名稱: | DMP4015SPSQ-13DITR |
| 工作溫度: | -55°C ~ 150°C (TJ) |
| 安裝類型: | Surface Mount |
| 濕度敏感度（MSL）: | 1 (Unlimited) |
| 製造商標準交貨期: | 16 Weeks |
| 製造商零件編號: | DMP4015SPSQ-13 |
| 輸入電容（Ciss）（Max）@ Vds: | 4234pF @ 20V |
| 柵極電荷（Qg）（Max）@ Vgs: | 47.5nC @ 5V |
| FET型: | P-Channel |
| FET特點: | - |
| 展開說明: | P-Channel 40V 8.5A (Ta) 1.3W (Ta) Surface Mount PowerDI5060-8 |
| 驅動電壓（最大Rds開，最小Rds開）: | 4.5V, 10V |
| 漏極至源極電壓（Vdss）: | 40V |
| 描述: | MOSFET P-CH 40V 8.5A POWER |
| 電流 - 25°C連續排水（Id）: | 8.5A (Ta) |
| Email: | [email protected] |
DMP4015SPSQ-13的相似型號
| 圖片 | 型號 | 製造商 | 描述 | 查看 |
|---|---|---|---|---|
 |
DMP4015SPS-13 | Diodes Incorporated | MOSFET P-CH 40V 8.5A POWERDI | 在線詢價 |
 |
DMP4013LFGQ-7 | Diodes Incorporated | MOSFET PCH 40V 10.3A POWERDI | 在線詢價 |
 |
DMP4025LK3-13 | Diodes Incorporated | MOSFET P-CH 40V 6.7A TO252 | 在線詢價 |
|
DMP4015SK3-13 | Diodes Incorporated | MOSFET P-CH 40V 14A TO252 DPAK | 在線詢價 |
 |
DMP4015SSSQ-13 | Diodes Incorporated | MOSFET P-CH 40V 9.1A 8-SO | 在線詢價 |
 |
DMP4047LFDE-7 | Diodes Incorporated | MOSFET P-CH 40V 3.3A U-DFN2020 | 在線詢價 |
|
DMP4015SSS-13 | Diodes Incorporated | MOSFET P-CH 40V 9.1A 8-SO | 在線詢價 |
 |
DMP4025SFG-13 | Diodes Incorporated | MOSFET P-CH 40V 4.65A POWERDI | 在線詢價 |
|
DMP4013LFG-7 | Diodes Incorporated | MOSFET P-CH 40V 10.3A PWRDI3333 | 在線詢價 |
|
DMP4015SK3Q-13 | Diodes Incorporated | MOSFET P-CH 40V 14A TO252 DPAK | 在線詢價 |
|
DMP4050SSDQ-13 | Diodes Incorporated | MOSFET 2P-CH 40V 4A 8SO | 在線詢價 |
|
DMP4013LFGQ-13 | Diodes Incorporated | MOSFET PCH 40V 10.3A POWERDI | 在線詢價 |
|
DMP4010SK3Q-13 | Diodes Incorporated | MOSFET P-CH 40V 50A TO252 | 在線詢價 |
