購買 DLW5BTM102SQ2L與BYCHPS
購買即有保證
DLW5BTM102SQ2L
- 型號:
- DLW5BTM102SQ2L
- 描述:
- CMC 2A 2LN 1 KOHM SMD
- 無鉛狀態/ RoHS狀態:
- 無鉛/符合RoHS
- 庫存數量:
- 16193 Pieces
簡單介紹
BYCHIPS是 DLW5BTM102SQ2L的现货代理商，我們有庫存立即運輸，也可供長時間供應。請寄給我們您的DLW5BTM102SQ2L購買計劃通過電子郵件，我們會根據您的計劃給您最優惠的價格。
產品特性
| 額定電壓 - 直流: | 50V |
|---|---|
| 額定電壓 - AC: | - |
| 尺寸/尺寸: | 0.197" L x 0.197" W (5.00mm x 5.00mm) |
| 系列: | DLW5B |
| 評級: | - |
| 封装: | Tape & Reel (TR) |
| 封裝/箱體: | Horizontal, 6 PC Pad |
| 其他名稱: | 490-7743-2 |
| 工作溫度: | -40°C ~ 85°C |
| 行數: | 2 |
| 安裝類型: | Surface Mount |
| 濕度敏感度（MSL）: | 1 (Unlimited) |
| 製造商標準交貨期: | 9 Weeks |
| 製造商零件編號: | DLW5BTM102SQ2L |
| 電感@頻率: | - |
| 頻率對應阻抗: | 1 kOhm @ 100MHz |
| 高度（最大）: | 0.098" (2.50mm) |
| 過濾器類型: | Power, Signal Line |
| 特徵: | - |
| 展開說明: | 2 Line Common Mode Choke Surface Mount 1 kOhm @ 100MHz 2A DCR 34 mOhm |
| 描述: | CMC 2A 2LN 1 KOHM SMD |
| 直流電阻（DCR）（最大值）: | 34 mOhm |
| 卡厚度（mm）: | 2A |
| 認證: | - |
| Email: | [email protected] |
