購買 DFEH10040D-1R5M=P3與BYCHPS
購買即有保證
DFEH10040D-1R5M=P3
- 型號:
- DFEH10040D-1R5M=P3
- 描述:
- FIXED IND 1.5UH 14A 5 MOHM
- 無鉛狀態/ RoHS狀態:
- 無鉛/符合RoHS
- 庫存數量:
- 13318 Pieces
簡單介紹
BYCHIPS是 DFEH10040D-1R5M=P3的现货代理商，我們有庫存立即運輸，也可供長時間供應。請寄給我們您的DFEH10040D-1R5M=P3購買計劃通過電子郵件，我們會根據您的計劃給您最優惠的價格。
產品特性
| 類型: | - |
|---|---|
| 公差: | ±20% |
| 供應商設備封裝: | - |
| 尺寸/尺寸: | 0.429" L x 0.394" W (10.90mm x 10.00mm) |
| 屏蔽: | Shielded |
| 系列: | DFEH10040D |
| 評級: | AEC-Q200 |
| Q因子@頻率: | - |
| 封装: | Tape & Reel (TR) |
| 封裝/箱體: | Nonstandard |
| 其他名稱: | 490-13092-2 |
| 工作溫度: | -40°C ~ 155°C |
| 安裝類型: | Surface Mount |
| 濕度敏感度（MSL）: | 1 (Unlimited) |
| 材料 - 核: | Powdered Iron |
| 製造商標準交貨期: | 13 Weeks |
| 製造商零件編號: | DFEH10040D-1R5M=P3 |
| 電感: | 1.5µH |
| 高度 - 座高（最大）: | 0.157" (4.00mm) |
| 頻率 - 測試: | 100MHz |
| 頻率 - 自諧振: | - |
| 展開說明: | 1.5µH Shielded Inductor 14A 5 mOhm Max Nonstandard |
| 描述: | FIXED IND 1.5UH 14A 5 MOHM |
| 直流電阻（DCR）: | 5 mOhm Max |
| 目前評級: | 14A |
| 電流 - 飽和: | 19A |
| Email: | [email protected] |
DFEH10040D-1R5M=P3的相似型號
| 圖片 | 型號 | 製造商 | 描述 | 查看 |
|---|---|---|---|---|
 |
DFEH10040D-2R2M=P3 | Murata Electronics North America | FIXED IND 2.2UH 12A 7.5 MOHM | 在線詢價 |
|
DFEH10040D-1R0M=P3 | Murata Electronics North America | FIXED IND 1UH 17A 3.5 MOHM | 在線詢價 |
|
DFEH10040D-8R2M=P3 | Murata Electronics North America | FIXED IND 8.2UH 5.9A 29 MOHM | 在線詢價 |
|
DFEH10040D-150M=P3 | Murata Electronics North America | FIXED IND 15UH 5.2A 47 MOHM | 在線詢價 |
|
DFEH10040D-4R7M=P3 | Murata Electronics North America | FIXED IND 4.7UH 8.8A 16 MOHM | 在線詢價 |
|
DFEH10040D-3R3M=P3 | Murata Electronics North America | FIXED IND 3.3UH 10A 12 MOHM | 在線詢價 |
|
DFEH10040D-5R6M=P3 | Murata Electronics North America | FIXED IND 5.6UH 8A 18 MOHM | 在線詢價 |
|
DFEH10040D-6R8M=P3 | Murata Electronics North America | FIXED IND 6.8UH 6.4A 23 MOHM | 在線詢價 |
|
DFEH10040D-100M=P3 | Murata Electronics North America | FIXED IND 10UH 5.7A 33 MOHM | 在線詢價 |
|
DFEH10040D-220M=P3 | Murata Electronics North America | FIXED IND 22UH 3.8A 70 MOHM | 在線詢價 |
