購買 CEDM8004VL TR與BYCHPS
購買即有保證
CEDM8004VL TR
- 型號:
- CEDM8004VL TR
- 描述:
- MOSFET P-CH 30V 0.45A SOT883
- 無鉛狀態/ RoHS狀態:
- 無鉛/符合RoHS
- 庫存數量:
- 12672 Pieces
簡單介紹
BYCHIPS是 CEDM8004VL TR的现货代理商，我們有庫存立即運輸，也可供長時間供應。請寄給我們您的CEDM8004VL TR購買計劃通過電子郵件，我們會根據您的計劃給您最優惠的價格。
產品特性
| VGS（TH）（最大）@標識: | 1V @ 250µA |
|---|---|
| Vgs（最大）: | 8V |
| 技術: | MOSFET (Metal Oxide) |
| 供應商設備封裝: | SOT-883VL |
| 系列: | - |
| RDS（ON）（最大值）@標識，柵極電壓: | 1.1 Ohm @ 430mA, 4.5V |
| 功率耗散（最大）: | 100mW (Ta) |
| 封装: | Tape & Reel (TR) |
| 封裝/箱體: | SC-101, SOT-883 |
| 工作溫度: | -65°C ~ 150°C (TJ) |
| 安裝類型: | Surface Mount |
| 濕度敏感度（MSL）: | 1 (Unlimited) |
| 製造商標準交貨期: | 6 Weeks |
| 製造商零件編號: | CEDM8004VL TR |
| 輸入電容（Ciss）（Max）@ Vds: | 55pF @ 25V |
| 柵極電荷（Qg）（Max）@ Vgs: | 0.88nC @ 4.5V |
| FET型: | P-Channel |
| FET特點: | - |
| 展開說明: | P-Channel 30V 450mA (Ta) 100mW (Ta) Surface Mount SOT-883VL |
| 驅動電壓（最大Rds開，最小Rds開）: | 1.8V, 4.5V |
| 漏極至源極電壓（Vdss）: | 30V |
| 描述: | MOSFET P-CH 30V 0.45A SOT883 |
| 電流 - 25°C連續排水（Id）: | 450mA (Ta) |
| Email: | [email protected] |
CEDM8004VL TR的相似型號
| 圖片 | 型號 | 製造商 | 描述 | 查看 |
|---|---|---|---|---|
 |
CEDM8001VL TR | Central Semiconductor Corp | MOSFET P-CH 20V 0.1A SOT883 | 在線詢價 |
 |
CEDM8001 TR | Central Semiconductor Corp | MOSFET P-CH 20V 0.1A SOT-883 | 在線詢價 |
 |
TK50P03M1(T6RSS-Q) | Toshiba Semiconductor and Storage | MOSFET N-CH 30V 50A DP TO252-3 | 在線詢價 |
 |
IPP65R065C7XKSA1 | Infineon Technologies | MOSFET N-CH 650V TO-220-3 | 在線詢價 |
|
CEDM8004 TR | Central Semiconductor Corp | MOSFET P-CH 30V 0.45A SOT883 | 在線詢價 |
|
CEDM8001 BK | Central Semiconductor Corp | MOSFET P-CH 20V 0.1A SOT-883 | 在線詢價 |
 |
STD7N65M2 | STMicroelectronics | MOSFET N-CH 650V 5A DPAK | 在線詢價 |
|
CEDM8004 BK | Central Semiconductor Corp | MOSFET P-CH 30V 0.45A SOT883 | 在線詢價 |
