購買 BUK7E2R7-30B,127與BYCHPS
購買即有保證
BUK7E2R7-30B,127
- 型號:
- BUK7E2R7-30B,127
- 描述:
- MOSFET N-CH 30V 75A I2PAK
- 無鉛狀態/ RoHS狀態:
- 無鉛/符合RoHS
- 庫存數量:
- 13299 Pieces
簡單介紹
BYCHIPS是 BUK7E2R7-30B,127的现货代理商，我們有庫存立即運輸，也可供長時間供應。請寄給我們您的BUK7E2R7-30B,127購買計劃通過電子郵件，我們會根據您的計劃給您最優惠的價格。
產品特性
| VGS（TH）（最大）@標識: | 4V @ 1mA |
|---|---|
| 技術: | MOSFET (Metal Oxide) |
| 供應商設備封裝: | I2PAK |
| 系列: | TrenchMOS™ |
| RDS（ON）（最大值）@標識，柵極電壓: | 2.7 mOhm @ 25A, 10V |
| 功率耗散（最大）: | 300W (Tc) |
| 封装: | Tube |
| 封裝/箱體: | TO-262-3 Long Leads, I²Pak, TO-262AA |
| 其他名稱: | 568-6629 568-6629-5 568-6629-ND 934058024127 BUK7E2R7-30B BUK7E2R7-30B,127-ND BUK7E2R7-30B-ND BUK7E2R730B127 |
| 工作溫度: | -55°C ~ 175°C (TJ) |
| 安裝類型: | Through Hole |
| 濕度敏感度（MSL）: | 1 (Unlimited) |
| 製造商零件編號: | BUK7E2R7-30B,127 |
| 輸入電容（Ciss）（Max）@ Vds: | 6212pF @ 25V |
| 柵極電荷（Qg）（Max）@ Vgs: | 91nC @ 10V |
| FET型: | N-Channel |
| FET特點: | - |
| 展開說明: | N-Channel 30V 75A (Tc) 300W (Tc) Through Hole I2PAK |
| 漏極至源極電壓（Vdss）: | 30V |
| 描述: | MOSFET N-CH 30V 75A I2PAK |
| 電流 - 25°C連續排水（Id）: | 75A (Tc) |
| Email: | [email protected] |
