購買 BCR12FM-14LJ#BB0與BYCHPS
購買即有保證
BCR12FM-14LJ#BB0
- 型號:
- BCR12FM-14LJ#BB0
- 描述:
- TRIAC 800V 12A
- 無鉛狀態/ RoHS狀態:
- 無鉛/符合RoHS
- 庫存數量:
- 13228 Pieces
簡單介紹
BYCHIPS是 BCR12FM-14LJ#BB0的现货代理商，我們有庫存立即運輸，也可供長時間供應。請寄給我們您的BCR12FM-14LJ#BB0購買計劃通過電子郵件，我們會根據您的計劃給您最優惠的價格。
產品特性
| 電壓 - 斷路: | 800V |
|---|---|
| 電壓 - 柵極觸發（VGT）（最大值）: | 1.5V |
| 三端雙向可控矽類型: | Standard |
| 供應商設備封裝: | TO-220FP |
| 系列: | - |
| 封装: | Tube |
| 封裝/箱體: | TO-220-3 Full Pack |
| 工作溫度: | -40°C ~ 150°C (TJ) |
| 安裝類型: | Through Hole |
| 濕度敏感度（MSL）: | 1 (Unlimited) |
| 製造商標準交貨期: | 16 Weeks |
| 製造商零件編號: | BCR12FM-14LJ#BB0 |
| 展開說明: | TRIAC Standard 800V 12A Through Hole TO-220FP |
| 描述: | TRIAC 800V 12A |
| 電流 - 導通狀態（IT（RMS））（最大）: | 12A |
| 電流 - 非眾議員浪湧50，60赫茲（ITSM）: | 120A @ 60Hz |
| 電流 - 柵極觸發（IGT）（最大值）: | 30mA |
| 組態: | Single |
| Email: | [email protected] |
