購買 BAS16T,115與BYCHPS
購買即有保證
BAS16T,115
- 型號:
- BAS16T,115
- 描述:
- DIODE GEN PURP 100V 155MA SC75
- 無鉛狀態/ RoHS狀態:
- 無鉛/符合RoHS
- 庫存數量:
- 12469 Pieces
- 數據表:
- BAS16T,115.pdf
簡單介紹
BYCHIPS是 BAS16T,115的现货代理商，我們有庫存立即運輸，也可供長時間供應。請寄給我們您的BAS16T,115購買計劃通過電子郵件，我們會根據您的計劃給您最優惠的價格。
產品特性
| 電壓 - 正向（Vf）（最大）: | 1.25V @ 150mA |
|---|---|
| 電壓 - （Vr）（最大）: | 100V |
| 供應商設備封裝: | SC-75 |
| 速度: | Small Signal =< 200mA (Io), Any Speed |
| 系列: | - |
| 反向恢復時間（trr）: | 4ns |
| 封装: | Tape & Reel (TR) |
| 封裝/箱體: | SC-75, SOT-416 |
| 其他名稱: | 568-5997-2 934054831115 BAS16T T/R BAS16T T/R-ND BAS16T,115-ND |
| 工作溫度 - 結: | 150°C (Max) |
| 安裝類型: | Surface Mount |
| 濕度敏感度（MSL）: | 1 (Unlimited) |
| 製造商零件編號: | BAS16T,115 |
| 展開說明: | Diode Standard 100V 155mA (DC) Surface Mount SC-75 |
| 二極管類型: | Standard |
| 描述: | DIODE GEN PURP 100V 155MA SC75 |
| 電流 - Vr時反向漏電: | 500nA @ 80V |
| 電流 - 平均整流（Io）: | 155mA (DC) |
| 電容@ Vr，F時: | 1.5pF @ 0V, 1MHz |
| Email: | [email protected] |
BAS16T,115的相似型號
