購買 74485540120與BYCHPS
購買即有保證
74485540120
- 型號:
- 74485540120
- 描述:
- INDUCT ARRAY 2 COIL 1.2UH SMD
- 無鉛狀態/ RoHS狀態:
- 無鉛/符合RoHS
- 庫存數量:
- 19312 Pieces
- 數據表:
- 74485540120.pdf
簡單介紹
BYCHIPS是 74485540120的现货代理商，我們有庫存立即運輸，也可供長時間供應。請寄給我們您的74485540120購買計劃通過電子郵件，我們會根據您的計劃給您最優惠的價格。
產品特性
| 公差: | ±20% |
|---|---|
| 測試電感 - 串聯連接: | 4.8µH |
| 尺寸/尺寸: | 0.610" L x 0.520" W (15.50mm x 13.20mm) |
| 屏蔽: | Shielded |
| 系列: | WE-CFWI |
| 封装: | Tape & Reel (TR) |
| 封裝/箱體: | 4-SMD |
| 其他名稱: | 732-4560-2 |
| 工作溫度: | -40°C ~ 150°C |
| 線圈的數目: | 2 |
| 安裝類型: | Surface Mount |
| 濕度敏感度（MSL）: | 1 (Unlimited) |
| 製造商標準交貨期: | 14 Weeks |
| 製造商零件編號: | 74485540120 |
| 電感 - 並行連接: | 1.2µH |
| 高度: | 0.413" (10.50mm) |
| 展開說明: | Shielded Coil Inductor Array Inductance - Connected in Series Inductance - Connected in Parallel 3.84 mOhm Max DC Resistance (DCR) - Parallel 4-SMD |
| 描述: | INDUCT ARRAY 2 COIL 1.2UH SMD |
| 直流電阻（DCR） - 系列: | - |
| 直流電阻（DCR） - 並聯: | 3.84 mOhm Max |
| 當前飽和度 - 系列: | 23.5A |
| 當前飽和度 - 平行: | 47A |
| 電流額定值 - 系列: | 11.5A |
| 電流額定值 - 並聯: | 23A |
| Email: | [email protected] |
