購買 4-1904124-3與BYCHPS
購買即有保證
4-1904124-3
- 型號:
- 4-1904124-3
- 描述:
- RELAY AUTOMOTIVE SPDT 30A 12V
- 無鉛狀態/ RoHS狀態:
- 無鉛/符合RoHS
- 庫存數量:
- 13449 Pieces
- 數據表:
- 4-1904124-3.pdf
簡單介紹
BYCHIPS是 4-1904124-3的现货代理商，我們有庫存立即運輸，也可供長時間供應。請寄給我們您的4-1904124-3購買計劃通過電子郵件，我們會根據您的計劃給您最優惠的價格。
產品特性
| 開啟電壓（最大值）: | 7.2 VDC |
|---|---|
| 關閉電壓（最小）: | 1.6 VDC |
| 端接類型: | Plug In, Quick Connect - Multiple Sizes |
| 切換電壓: | 12VDC - Nom |
| 系列: | Micro Relay A |
| 繼電器類型: | Automotive |
| 封装: | Bulk |
| 其他名稱: | 8-1393292-4 8-1393292-4-ND V23074-A1001-A403 V23074A1001A403 |
| 工作溫度: | -40°C ~ 125°C |
| 安裝類型: | Socketable |
| 濕度敏感度（MSL）: | 1 (Unlimited) |
| 製造商標準交貨期: | 29 Weeks |
| 製造商零件編號: | 4-1904124-3 |
| 特徵: | Resistor |
| 展開說明: | Automotive Relay SPDT (1 Form C) 12VDC Coil Socketable |
| 描述: | RELAY AUTOMOTIVE SPDT 30A 12V |
| 觸點額定值（電流）: | 30A |
| 觸點材料: | Silver Alloy |
| 聯繫表: | SPDT (1 Form C) |
| 線圈電壓: | 12VDC |
| 線圈類型: | Non Latching |
| 線圈電阻: | 119 Ohms |
| 線圈功率: | 1.2 W |
| Email: | [email protected] |
