337LBA250M2CD
- 型號:
- 337LBA250M2CD
- 描述:
- CAP ALUM 330UF 20% 250V SNAP
- 無鉛狀態/ RoHS狀態:
- 無鉛/符合RoHS
- 庫存數量:
- 13628 Pieces
簡單介紹
BYCHIPS是 337LBA250M2CD的现货代理商，我們有庫存立即運輸，也可供長時間供應。請寄給我們您的337LBA250M2CD購買計劃通過電子郵件，我們會根據您的計劃給您最優惠的價格。
產品特性
| 額定電壓: | 250V |
|---|---|
| 公差: | ±20% |
| 表面貼裝佔地面積: | - |
| 尺寸/尺寸: | 0.984" Dia (25.00mm) |
| 系列: | LBA |
| 紋波電流: | 1.67A |
| 極化: | Polar |
| 封装: | Bulk |
| 封裝/箱體: | Radial, Can - Snap-In |
| 工作溫度: | -40°C ~ 85°C |
| 安裝類型: | Through Hole |
| 濕度敏感度（MSL）: | 1 (Unlimited) |
| 製造商標準交貨期: | 16 Weeks |
| 製造商零件編號: | 337LBA250M2CD |
| 壽命@溫度。: | 2000 Hrs @ 85°C |
| 引線間距: | 0.394" (10.00mm) |
| 阻抗: | - |
| 高度 - 座高（最大）: | 1.260" (32.00mm) |
| 展開說明: | 330µF 250V Aluminum Capacitors Radial, Can - Snap-In 753.57 mOhm @ 120Hz 2000 Hrs @ 85°C |
| ESR（等效串聯電阻）: | 753.57 mOhm @ 120Hz |
| 描述: | CAP ALUM 330UF 20% 250V SNAP |
| 電容: | 330µF |
| 應用: | General Purpose |
| Email: | [email protected] |
