購買 2SCR346PT100Q與BYCHPS
購買即有保證
2SCR346PT100Q
- 型號:
- 2SCR346PT100Q
- 描述:
- NPN 100MA 400V MIDDLE POWER TRAN
- 無鉛狀態/ RoHS狀態:
- 無鉛/符合RoHS
- 庫存數量:
- 13617 Pieces
簡單介紹
BYCHIPS是 2SCR346PT100Q的现货代理商，我們有庫存立即運輸，也可供長時間供應。請寄給我們您的2SCR346PT100Q購買計劃通過電子郵件，我們會根據您的計劃給您最優惠的價格。
產品特性
| 電壓 - 集電極發射極擊穿（最大）: | 400V |
|---|---|
| Vce飽和（最大）@ IB，IC: | 300mV @ 2mA, 20mA |
| 晶體管類型: | NPN |
| 供應商設備封裝: | MPT3 |
| 系列: | - |
| 功率 - 最大: | 500mW |
| 封装: | Cut Tape (CT) |
| 封裝/箱體: | TO-243AA |
| 其他名稱: | 2SCR346PT100QCT |
| 工作溫度: | 150°C (TJ) |
| 安裝類型: | Surface Mount |
| 濕度敏感度（MSL）: | 1 (Unlimited) |
| 製造商標準交貨期: | 10 Weeks |
| 製造商零件編號: | 2SCR346PT100Q |
| 頻率 - 轉換: | - |
| 展開說明: | Bipolar (BJT) Transistor NPN 400V 100mA 500mW Surface Mount MPT3 |
| 描述: | NPN 100MA 400V MIDDLE POWER TRAN |
| 直流電流增益（HFE）（最小值）@ IC，的Vce: | 82 @ 10mA, 10V |
| 電流 - 集電極截止（最大）: | 10µA (ICBO) |
| 電流 - 集電極（Ic）（最大）: | 100mA |
| Email: | [email protected] |
2SCR346PT100Q的相似型號
| 圖片 | 型號 | 製造商 | 描述 | 查看 |
|---|---|---|---|---|
 |
2SCR346PT100P | Rohm Semiconductor | NPN 100MA 400V MIDDLE POWER TRAN | 在線詢價 |
|
2SCR372P5T100R | Rohm Semiconductor | NPN 120V 700MA MEDIUM POWER DRIV | 在線詢價 |
 |
2N6387 | ON Semiconductor | TRANS NPN DARL 60V 10A TO220AB | 在線詢價 |
|
2SCR372P5T100Q | Rohm Semiconductor | NPN 120V 700MA MEDIUM POWER DRIV | 在線詢價 |
|
2SCR375P5T100Q | Rohm Semiconductor | NPN 120V 1.5A MEDIUM POWER TRANS | 在線詢價 |
|
2SCR372PT100R | Rohm Semiconductor | TRANS NPN 120V 0.7A MPT3 | 在線詢價 |
 |
TIP29B-BP | Micro Commercial Co | TRANS NPN 80V 1A TO-220 | 在線詢價 |
 |
BC327,412 | NXP USA Inc. | TRANS PNP 45V 0.5A TO-92 | 在線詢價 |
|
2SCR372PT100Q | Rohm Semiconductor | TRANS NPN 120V 0.7A MPT3 | 在線詢價 |
 |
MPSA12G | ON Semiconductor | TRANS NPN DARL 20V TO-92 | 在線詢價 |
 |
JAN2N2880 | Microsemi Corporation | TRANS NPN 80V 5A TO59 | 在線詢價 |
|
BDX34C | ON Semiconductor | TRANS PNP DARL 100V 10A TO-220AB | 在線詢價 |
 |
2SC248000L | Panasonic Electronic Components | TRANS NPN 20V 0.05A MINI 3P | 在線詢價 |
|
2SA1708S-YMH-AN | ON Semiconductor | TRANS BIPO NMP | 在線詢價 |
|
2SCR375P5T100R | Rohm Semiconductor | NPN 120V 1.5A MEDIUM POWER TRANS | 在線詢價 |
