購買 2SC6114T2LQ與BYCHPS
購買即有保證
2SC6114T2LQ
- 型號:
- 2SC6114T2LQ
- 描述:
- TRANS NPN 50V 0.1A VMN3
- 無鉛狀態/ RoHS狀態:
- 無鉛/符合RoHS
- 庫存數量:
- 15298 Pieces
- 數據表:
- 2SC6114T2LQ.pdf
簡單介紹
BYCHIPS是 2SC6114T2LQ的现货代理商，我們有庫存立即運輸，也可供長時間供應。請寄給我們您的2SC6114T2LQ購買計劃通過電子郵件，我們會根據您的計劃給您最優惠的價格。
產品特性
| 電壓 - 集電極發射極擊穿（最大）: | 50V |
|---|---|
| Vce飽和（最大）@ IB，IC: | 300mV @ 2.5mA, 25mA |
| 晶體管類型: | NPN |
| 供應商設備封裝: | VMN3 |
| 系列: | - |
| 功率 - 最大: | 150mW |
| 封装: | Tape & Reel (TR) |
| 封裝/箱體: | SC-72 Formed Leads |
| 工作溫度: | 150°C (TJ) |
| 安裝類型: | Surface Mount |
| 濕度敏感度（MSL）: | 1 (Unlimited) |
| 製造商零件編號: | 2SC6114T2LQ |
| 頻率 - 轉換: | 130MHz |
| 展開說明: | Bipolar (BJT) Transistor NPN 50V 100mA 130MHz 150mW Surface Mount VMN3 |
| 描述: | TRANS NPN 50V 0.1A VMN3 |
| 直流電流增益（HFE）（最小值）@ IC，的Vce: | 120 @ 2mA, 6V |
| 電流 - 集電極截止（最大）: | 100nA (ICBO) |
| 電流 - 集電極（Ic）（最大）: | 100mA |
| Email: | [email protected] |
