購買 2SC54190RA與BYCHPS
購買即有保證
2SC54190RA
- 型號:
- 2SC54190RA
- 製造商:
- Panasonic
- 描述:
- TRANS NPN 300V 0.07A MT-2
- 無鉛狀態/ RoHS狀態:
- 無鉛/符合RoHS
- 庫存數量:
- 16629 Pieces
- 數據表:
- 2SC54190RA.pdf
簡單介紹
BYCHIPS是 2SC54190RA的现货代理商，我們有庫存立即運輸，也可供長時間供應。請寄給我們您的2SC54190RA購買計劃通過電子郵件，我們會根據您的計劃給您最優惠的價格。
產品特性
| 電壓 - 集電極發射極擊穿（最大）: | 300V |
|---|---|
| Vce飽和（最大）@ IB，IC: | 1.2V @ 5mA, 50mA |
| 晶體管類型: | NPN |
| 供應商設備封裝: | MT-2-A1 |
| 系列: | - |
| 功率 - 最大: | 1W |
| 封装: | Cut Tape (CT) |
| 封裝/箱體: | 3-SIP |
| 其他名稱: | 2SC54190RACT |
| 工作溫度: | 150°C (TJ) |
| 安裝類型: | Through Hole |
| 濕度敏感度（MSL）: | 1 (Unlimited) |
| 製造商零件編號: | 2SC54190RA |
| 頻率 - 轉換: | 50MHz |
| 展開說明: | Bipolar (BJT) Transistor NPN 300V 70mA 50MHz 1W Through Hole MT-2-A1 |
| 描述: | TRANS NPN 300V 0.07A MT-2 |
| 直流電流增益（HFE）（最小值）@ IC，的Vce: | 100 @ 5mA, 10V |
| 電流 - 集電極截止（最大）: | 1µA |
| 電流 - 集電極（Ic）（最大）: | 70mA |
| Email: | [email protected] |
