購買 1904001-2與BYCHPS
購買即有保證
1904001-2
- 型號:
- 1904001-2
- 描述:
- RELAY AUTO SPST-NO 75A 12V
- 無鉛狀態/ RoHS狀態:
- 無鉛/符合RoHS
- 庫存數量:
- 19964 Pieces
- 數據表:
- 1904001-2.pdf
簡單介紹
BYCHIPS是 1904001-2的现货代理商，我們有庫存立即運輸，也可供長時間供應。請寄給我們您的1904001-2購買計劃通過電子郵件，我們會根據您的計劃給您最優惠的價格。
產品特性
| 開啟電壓（最大值）: | 8 VDC |
|---|---|
| 關閉電壓（最小）: | 4 VDC |
| 端接類型: | Screw Terminal |
| 切換電壓: | 12VDC - Nom |
| 系列: | HCR 75 |
| 發布時間: | 15ms |
| 繼電器類型: | Automotive |
| 封装: | Bulk |
| 其他名稱: | 1904001-2-ND 19040012 PB1900 V23232A0001X003-EV-260 |
| 工作溫度: | -40°C ~ 100°C |
| 操作時間: | 10ms |
| 安裝類型: | Chassis Mount |
| 濕度敏感度（MSL）: | 1 (Unlimited) |
| 製造商標準交貨期: | 19 Weeks |
| 製造商零件編號: | 1904001-2 |
| 特徵: | - |
| 展開說明: | Automotive Relay SPST-NO (1 Form A) 12VDC Coil Chassis Mount |
| 描述: | RELAY AUTO SPST-NO 75A 12V |
| 觸點額定值（電流）: | 75A |
| 觸點材料: | Silver (Ag) |
| 聯繫表: | SPST-NO (1 Form A) |
| 線圈電壓: | 12VDC |
| 線圈類型: | Non Latching |
| 線圈電阻: | 46 Ohms |
| 線圈功率: | - |
| Email: | [email protected] |
