購買 1462043-3與BYCHPS
購買即有保證
1462043-3
- 型號:
- 1462043-3
- 描述:
- RELAY TELECOM DPST-NO 2A 5V
- 無鉛狀態/ RoHS狀態:
- 無鉛/符合RoHS
- 庫存數量:
- 18592 Pieces
- 數據表:
- 1462043-3.pdf
簡單介紹
BYCHIPS是 1462043-3的现货代理商，我們有庫存立即運輸，也可供長時間供應。請寄給我們您的1462043-3購買計劃通過電子郵件，我們會根據您的計劃給您最優惠的價格。
產品特性
| 開啟電壓（最大值）: | 3.75 VDC |
|---|---|
| 關閉電壓（最小）: | 0.5 VDC |
| 端接類型: | Gull Wing |
| 切換電壓: | 250VAC, 220VDC - Max |
| 系列: | IM, AXICOM |
| 發布時間: | 3ms |
| 繼電器類型: | Telecom |
| 封装: | Original-Reel® |
| 其他名稱: | PB2067DKR |
| 工作溫度: | -40°C ~ 85°C |
| 操作時間: | 3ms |
| 安裝類型: | Surface Mount |
| 濕度敏感度（MSL）: | 1 (Unlimited) |
| 製造商標準交貨期: | 13 Weeks |
| 製造商零件編號: | 1462043-3 |
| 特徵: | Sealed - Hermetically |
| 展開說明: | Telecom Relay DPST (2 Form A) Surface Mount |
| 描述: | RELAY TELECOM DPST-NO 2A 5V |
| 觸點額定值（電流）: | 2A |
| 觸點材料: | Palladium (Pd), Ruthenium (Ru), Gold (Au) |
| 聯繫表: | DPST (2 Form A) |
| 線圈電壓: | 5VDC |
| 線圈類型: | Non Latching |
| 線圈電阻: | 178 Ohms |
| 線圈功率: | 140 mW |
| 線圈電流: | 28.1mA |
| Email: | [email protected] |
