購買 STL40C30H3LL與BYCHPS
購買即有保證
STL40C30H3LL
- 型號:
- STL40C30H3LL
- 製造商:
- ST
- 描述:
- MOSFET N/P-CH 30V POWERFLAT
- 無鉛狀態/ RoHS狀態:
- 無鉛/符合RoHS
- 庫存數量:
- 13836 Pieces
- 數據表:
- STL40C30H3LL.pdf
簡單介紹
BYCHIPS是 STL40C30H3LL的现货代理商，我們有庫存立即運輸，也可供長時間供應。請寄給我們您的STL40C30H3LL購買計劃通過電子郵件，我們會根據您的計劃給您最優惠的價格。
產品特性
| VGS（TH）（最大）@標識: | 1V @ 250µA (Min) |
|---|---|
| 供應商設備封裝: | PowerFlat™ (5x6) |
| 系列: | STripFET™ VI |
| RDS（ON）（最大值）@標識，柵極電壓: | 21 mOhm @ 4A, 10V |
| 功率 - 最大: | 60W |
| 封装: | Tape & Reel (TR) |
| 封裝/箱體: | 8-PowerVDFN |
| 其他名稱: | 497-15314-2 |
| 工作溫度: | -55°C ~ 150°C (TJ) |
| 安裝類型: | Surface Mount |
| 濕度敏感度（MSL）: | 1 (Unlimited) |
| 製造商標準交貨期: | 18 Weeks |
| 製造商零件編號: | STL40C30H3LL |
| 輸入電容（Ciss）（Max）@ Vds: | 475pF @ 24V |
| 柵極電荷（Qg）（Max）@ Vgs: | 4.6nC @ 4.5V |
| FET型: | N and P-Channel |
| FET特點: | Logic Level Gate |
| 展開說明: | Mosfet Array N and P-Channel 30V 40A, 30A 60W Surface Mount PowerFlat™ (5x6) |
| 漏極至源極電壓（Vdss）: | 30V |
| 描述: | MOSFET N/P-CH 30V POWERFLAT |
| 電流 - 25°C連續排水（Id）: | 40A, 30A |
| Email: | [email protected] |
