購買 IXTR32P60P與BYCHPS
購買即有保證
IXTR32P60P
- 型號:
- IXTR32P60P
- 製造商:
- IXYS Corporation
- 描述:
- MOSFET P-CH 600V 18A ISOPLUS247
- 無鉛狀態/ RoHS狀態:
- 無鉛/符合RoHS
- 庫存數量:
- 15199 Pieces
- 數據表:
- IXTR32P60P.pdf
簡單介紹
BYCHIPS是 IXTR32P60P的现货代理商，我們有庫存立即運輸，也可供長時間供應。請寄給我們您的IXTR32P60P購買計劃通過電子郵件，我們會根據您的計劃給您最優惠的價格。
產品特性
| VGS（TH）（最大）@標識: | 4V @ 1mA |
|---|---|
| 技術: | MOSFET (Metal Oxide) |
| 供應商設備封裝: | ISOPLUS247™ |
| 系列: | PolarP™ |
| RDS（ON）（最大值）@標識，柵極電壓: | 385 mOhm @ 16A, 10V |
| 功率耗散（最大）: | 310W (Tc) |
| 封装: | Tube |
| 封裝/箱體: | ISOPLUS247™ |
| 工作溫度: | -55°C ~ 150°C (TJ) |
| 安裝類型: | Through Hole |
| 濕度敏感度（MSL）: | 1 (Unlimited) |
| 製造商標準交貨期: | 8 Weeks |
| 製造商零件編號: | IXTR32P60P |
| 輸入電容（Ciss）（Max）@ Vds: | 11100pF @ 25V |
| 柵極電荷（Qg）（Max）@ Vgs: | 196nC @ 10V |
| FET型: | P-Channel |
| FET特點: | - |
| 展開說明: | P-Channel 600V 18A (Tc) 310W (Tc) Through Hole ISOPLUS247™ |
| 漏極至源極電壓（Vdss）: | 600V |
| 描述: | MOSFET P-CH 600V 18A ISOPLUS247 |
| 電流 - 25°C連續排水（Id）: | 18A (Tc) |
| Email: | [email protected] |
